T&S ELECTRONIC SENSOR LAV FAUCET 4OC
EC-3103
779502
67126266773
- AC/DC POWER, DECK MOUNT TYPE
- 71 INCH CORD LENGTH
- 100 TO 240 VOLT AC INPUT SUPPLY RATING
- 2.2 GPM AT 60 PSI FLOW RATE
- POLISHED CHROME PLATED COLOR/FINISH
- ADA, ANSI A117.1, ASME A112.18.1, CSA B125.1, CEC-400, EPA, UL (CANADA AND US), NSF 61/372, TAA APPLICABLE STANDARD
- WATER RESISTANT CONTROL MODULE WITH INTERNAL FLOW CONTROL SWITCH, AUTO FLUSH FEATURE, LOW BATTERY LED INDICATOR LIGHT, TEMPERATURE CONTROL MIXING VALVE, CHECK VALVE, FLEXIBLE STAINLESS STEEL SUPPLY HOSE, FURNISHED WITH VANDAL-RESISTANT KEY, 24 INCH SENSOR CABLE, AC TRANSFORMER INCLUSIONS/FEATURES
- SOLID CAST BRASS BODY MATERIAL
- COMPRESSION INLET CONNECTION
- 3/8 INCH INLET SIZE
- 4 INCH FAUCET HOLE CENTER
- CENTERSET SPOUT TYPE
- 5-1/16 INCH HEIGHT X 4-1/16 INCH CLEARANCE X 4-7/8 INCH REACH SPOUT DIMENSIONS
- SOLID CAST BRASS SPOUT MATERIAL
- VANDAL RESISTANT AERATOR TYPE
- (4) AA ALKALINE BATTERY DETAILS
- CHEKPOINT[TM] BRAND
- LEAD-FREE
- PRESSURE RATING 20 TO 125 PSI
- TEMPERATURE RATING 40 TO 140 DEG F
67126266773
